CROBOTP · Palletizing Robots
CRP-RP32-180
CROBOTP CRP-RP32-180 4-axis palletizing robot with 180 kg payload, 3,130 mm reach, ±0.1mm repeatability. Controller: G15A.
Payload180 kg
Reach3,130 mm
Repeatability±0.1 mm
Axes4 axes
Weight845 kg
IP ratingBody IP54, wrist IP67
Controller: G15A
Specifications CRP-RP32-180
| Model | CRP-RP32-180 |
| Arm form | Multi-joint with parallel link |
| Axes | 4 axes |
| Max payload | 180 kg |
| Max reach | 3,130 mm |
| Repeatability | ±0.1 mm |
| Robot weight | 845 kg |
| Mounting | Floor mounting |
| Reserved I/O | 26 pin |
| Reserved air | 2 × Ø12 mm |
| Protection | Body IP54, wrist IP67 |
| Operating temperature | 0 ~ 45°C |
| Humidity | 20–80% RH, non-condensing |
| Vibration | Under 0.5 G |
| Applications | Handling, palletizing, depalletizing, loading and unloading |
| Controller | G15A |
Data source: CROBOTP Product Catalog (KUNG edition), PDF page 40. Specifications are taken from the latest manufacturer documents supplied to TWT and may change by production year. Please confirm with our sales team before ordering.
Joint range, speed and allowable load
| Axis | Range | Max speed | Allowable torque | Allowable inertia |
|---|---|---|---|---|
| J1 | ±175° | 135°/s | – | – |
| J2 | -85° ~ 35° | 130°/s | – | – |
| J3 | -70° ~ 100° | 130°/s | – | – |
| J4 | ±360° | 280°/s | 190 N·m | 50 kg·m² |
Downloads
FAQ
What payload can the CRP-RP32-180 handle?
Up to 180 kg including the end effector, with a maximum reach of 3,130 mm.
Which controller does the CRP-RP32-180 use?
It is matched with the CROBOTP G15A control cabinet. See the controller category for cabinet specifications.
What is the protection rating?
Body IP54,wrist IP67.
How do I get a price for the CRP-RP32-180?
Send the request form on this page or add LINE @TWTROBOT. Our team replies with a quotation.
